SharePoint 2010 Picture Libraries and the Datasheet View

Picture Libraries in SharePoint 2010 appear to support the Datasheet view but it is not available as an option through the UI.

Warning: As always use this method at your own risk.  I have tested it and so far it works fine.  If you run into an issue using this method please leave a comment so that I can update this post.

Brief How To

  1. Go to a document library and open a datasheet view.
  2. Replace the view URL and the View GUID with a URL and GUID of your picture library

Detailed How To


Go to a regular document library in the same site as your picture library and open the datasheet view.  Copy the URL.  It will look something like this:

hxxp://a.b.com/tests/picgridtest/Shared%20Documents/Forms/AllItems.aspx?ShowInGrid=True&View=%7B4789A2DC%2D357E%2D4046%2D8E0E%2DF84294697D9E%7D&InitialTabId=Ribbon%2ELibrary&VisibilityContext=WSSTabPersistence

The highlighted areas need to be changed to work with your picture library.  The first area needs to be changed to your picture library and the correct view.  The View GUID needs to be changed to the GUID of the picture library view you are going to use.  Note in this example I am going to use the default allitems view.  It may work better for you to create a view just for this purpose because some columns in the allitems view are read-only.

Go back to your picture library and browse to the view you would like to use.  Copy this URL and paste it into your favorite text editor.

hxxp://a.b.com/tests/picgridtest/Picture%20Grid%20View/Forms/AllItems.aspx

This is the first portion of our new URL.

Next click modify this view.


After the Edit View page loads copy the view GUID out of the URL.  My view URL is below and I copied out the highlighted text.

hxxp://a.b.com/tests/picgridtest/_layouts/ViewEdit.aspx?List=%7B1A5C6954%2DA6CF%2D4EA3%2D815C%2D9CD20B25FABC%7D&View=%7B8AE2BF13%2D0CE3%2D44CF%2DA639%2D16FBF281201B%7D&Source=http%253A%252F%252Fintranet%252Edemo%252Ecom%252Ftests%252Fpicgridtest%252F%255Flayouts%252Fvsmenu%252Easpx%253FList%253D%257B1a5c6954%252Da6cf%252D4ea3%252D815c%252D9cd20b25fabc%257D%2526View%253D%257B8ae2bf13%252D0ce3%252D44cf%252Da639%252D16fbf281201b%257D%2526Source%253Dhttp%253A%252F%252Fintranet%252Edemo%252Ecom%252Ftests%252Fpicgridtest%252FPicture%25252520Grid%25252520View%252FForms%252FAllItems%252Easpx%2526

The highlighted portion of the URL above is the second part of our URL that needs to be changed.

Now we have the two parts we need and we can build the final URL. The following format and text will be used.  Just paste in the text copied out previously into the highlighted areas of the formula.

Formula: [1 View URL]?ShowInGrid=True&View=[2 View GUID]&InitialTabId=Ribbon%2ELibrary&VisibilityContext=WSSTabPersistence

Part 1: hxxp://a.b.com/tests/picgridtest/Picture%20Grid%20View/Forms/AllItems.aspx

Part 2: %7B8AE2BF13%2D0CE3%2D44CF%2DA639%2D16FBF281201B%7D

The final URL will look something like this:

hxxp://a.b.com/tests/picgridtest/Picture%20Grid%20View/Forms/AllItems.aspx?ShowInGrid=True&View=%7B8AE2BF13%2D0CE3%2D44CF%2DA639%2D16FBF281201B%7D&InitialTabId=Ribbon%2ELibrary&VisibilityContext=WSSTabPersistence

Paste this into your browser and you should be good to go.


Notes

  • Tested in SharePoint 2010, 14.0.5123.5000
  • I was not able to get this to work in SharePoint 2007
  • This is also possible using an Access view but I ran into many issues trying to copy data from one view to another and still could not drag and copy cells.
